Recommended use |
Mid‑High Loudspeaker for PA / Modular Systems |
Installation |
/ |
Output Power |
Driver 10″: 250W AES; Driver 1.4″: 75W AES |
Impedance |
10″: 24Ω; 1.4″: 32Ω |
Frequency Response |
200 Hz – 18 kHz (‑3 dB) |
Operating Voltage |
/ |
Number of Channels |
2‑way |
Connectivity Technology |
Wired |
Audio Output Mode |
Mid‑High Section |
Magnet Material |
Neodymium |
Diaphragm Material |
/ |
Control Method |
/ |
Radio Function |
No |
Shell Material |
Birch Plywood |
The Body Material |
Wood |
Shape |
/ |
Battery Type |
/ |
Product Charging Port |
/ |
Power Source |
Passive / Bi‑amp option |
Special Feature |
High Output, Controlled Directivity |
Connection Type |
Neutrik NL4 or NL8 option |
SNR |
/ |
Efficiency ‑ Type |
High Sensitivity |
Storage |
/ |
Warranty |
/ |
Model Number |
EVO 6EH |
Place of Origin |
/ |
Brand Name |
R&F Audio |
Dimension |
/ |
Format |
/ |
Product Name |
EVO 6EH Mid‑High Loudspeaker |
Application |
PA, Concert Systems, Modular Evo 6 Arrays |
Max SPL (1M) |
/ |
Size |
/ |
Weight |
38 kg (84 lbs) |
Drivers |
1 × 10″ (200 Hz‑4 kHz), 1 × 1.4″ (4 kHz‑up) |
Nominal Dispersion |
50° Horizontal × 25° Vertical |
Packaging and Delivery ‑ Selling Units |
Single item |
Packaging and Delivery ‑ Single Package Size |
/ |
Packaging and Delivery ‑ Single Gross Weight |
/ |
